Product view
The best breathing protection class – TH3
During arc welding, grinding and many other dust-intensive activities, your airways are always exposed to harmful smoke, dust and often toxic gases. Wearing a personal breathing protection system is therefore essential – no matter how well ventilated your working environment may be.
That‘s why the new e3000X offers you a highly modular breathing protection solution that you can adapt to your protection needs in seconds.
99.8% cleaned air. Perfect protection.
Compared to the widely available TH2 systems, TH3-certified breathing protection systems filter 10 times more dirt out of the air, or in other words: 99.8% of the harmful particles are filtered out of the air.

This association of many leading manufacturers is intensively involved in protecting welders from hazardous fumes and pollutants in the workplace.
The e3000X PAPR system is now ATEX Zone 2 and 22 certified.
What does ATEX actually mean?
ATEX stands for "ATmosphere EXplosible" and refers to the safety of equipment and systems such as the e3000X PAPR system. ATEX-certified equipment and systems must be used when explosive atmospheres can occur.
What are explosive atmospheres?
An explosive atmosphere is one in which materials such as gases, vapours or dusts reach a concentration which, together with air or oxygen, can trigger an explosion.
Natural processes, industrial activities or human error can all cause explosive atmospheres. Explosive atmospheres mostly occur indoors, but are also found outdoors, for example in mines.
Examples of explosive materials are:
- Flammable gases such as methane, propane and butane
- Flammable vapours such as petrol, diesel and alcohol
- Combustible dusts such as wood, metal and plastic dusts
How do you know that you need ATEX-certified equipment?
There is always reason enough for a PAPR system with ATEX Zone 2 and 22 certification.
But if your safety officer or any national or industry legal regulations require ATEX-certified equipment, you must check whether a unit for Zones 2 and 22 is sufficient.
X-tended Application Possibilities
The new optrel e3000x reliably protects you from particles such as smoke, aerosols and dust. In addition, the mountainbreeze Odor/Ozon Filter protects you from unpleasant odours and harmful ozone. In environments with harmful or even toxic gases, the A1B1E1 gas filter reliably protects you from organic, inorganic and acid gases. The new e3000x easily adapts to your needs.
X-tended Performance
Efficiency is achieving as much air output as possible with as little energy as possible. We have managed to double the efficiency of the new e3000X by combining a performance-optimized design with the latest battery cell technology.
With up to 18 hours of battery life and 240 litres of air per minute available at the touch of a button, the new e3000X is the perfect choice for the most powerful ventilated breathing protection system available on the market.
Organised energy management for your company
e3000X multibaycharger
Continuous workflow – up to zu 6 batteries charged simultaneously
Organised energy management – always the perfect overview
No more cable clutter
Smart construction for standing and wall mounting
LED display for each battery
Compatible with all batteries of the e3000 / e3000X Series
Further information and technical data can be found in the product brochure (PDF)
e3000X
X-tend your possibilities
Respiratory protection system with integrated air flow sensor and 3 level air flow adjustment.
With the new PAPR system e3000X optrel guarantees:
- Highest level protection (TH3) from smoke, aerosols and dust). The breathing air gets up to 500 times cleaner.
- Evenly distributed air inside the PAPR helmet without eye irritation.
- Automatic air flow control.
- Automatic air flow calibration
- Additional cooling effect for the fore head.
Better work conditions for more efficiency, comfort and performance.
Respiratory Protection
Particle Filter
TH3 Standard
Power battery pack
for higher Performance
Integrated
Air Flow Control
Adjustable
Air Flow
Easy to Use
mountain-breeze
Odor Filter
Ergonomic fit thanks
to shoulder harness
Fields of Application
- Welding
- Grinding
Variants

Article Nr. | Description | Units | Image |
---|---|---|---|
4088.100 | e3000/e3000X TH3P particle master filter | 1 | ![]() |
4088.700 | ABE1 gas filter insert for e3000X PAPR system | 1 | ![]() |
4088.101 | e3000/e3000X Prefilter | 50 | ![]() |
4088.102 | e3000/e3000X Spark protector | 2 | ![]() |
4551.020 | e3000/e3000X Air hose | 1 | ![]() |
4551.070 | e3000/e3000X Charger with all plugs (EU/AUS/UK/US) | ![]() | |
4551.023 | e3000/e3000X Sealing kit for e3000/e3000X & mountain breeze filter kit | 1 | ![]() |
4551.024 | e3000/e3000X air hose holder | 1 | ![]() |
4157.000 | Face seal suitable for e600/vegaview helmets with hard hat | 1 | ![]() |
4160.400 | Faceseal for PAPR helmet | 1 | ![]() |
4160.000 | Face seal suitable for e600 helmets/vegaview | 1 | ![]() |
4160.100 | Face seal suitable for b630/p330 | 1 | ![]() |
4088.103 | mountain breeze odor filter unit with replacement filter e3000/e3000X | 1 | ![]() |
4088.104 | mountain breeze replacement odor filter e3000/e3000X | 1 | ![]() |
4551.021 | e3000/e3000X Protective sleeve for air hose black | 1 | ![]() |
4551.030 | e3000/e3000X adapter connector for e600 | 1 | ![]() |
4551.040 | e3000/e3000X shoulder harness | 1 | ![]() |
8000.110 | e3000/e3000X bag - black/green | 1 | ![]() |
4028.015 | Chest protection leather | 1 | ![]() |
4028.016 | Head & neck protection leather | 1 | ![]() |
4551.015.CH | multibaycharger e3000-Series CH-device power cord | 1 | ![]() |
4551.015.EU | multibaycharger e3000-Series EU-device power cord | 1 | ![]() |
4551.015.UK | multibaycharger e3000-Series UK-device power cord | 1 | ![]() |
4551.015.US | multibaycharger e3000-Series US-device power cord | 1 | ![]() |
Technical Data
Level 2: min. 210 l/min
Level 3: min. 240 l/min
AS/NZS 1716:2012,
EAC: TP TC 019/2011
ATEX Standards:
EN ISO 80079-36; EN 1127-1; EN 60079-0;
60079-15
II 3G Ex h II B T5 Gc
Documents
Further information
For further information pls refer to your optrel partner next to you or to our customer service.
